ASUS MH Series Clinical Displays Listed as Class 1 Devices by FDA, TFDA, and EU MDR

June 26, 2025

・

Press Release

Achieving FDA, TFDA and EU MDR listings, the ASUS MH series brings pinpoint DICOM-grade clarity and always-on calibration to every hospital workspace.

FDA, TFDA & EU MDR listings: MH3281A, MH2741A and MH2441A meet global medical-device standards
Visual accuracy and consistency: DICOM Part 14 compliance, auto calibration and ensure accurate radiology/PACS visuals

TAIPEI, Taiwan, June 23, 2025 — ASUS today announced that the latest MH series clinical displays have been listed as Class 1 devices by the US Food and Drug Administration (FDA), the Taiwan Food and Drug Administration (TFDA), and the European Union Medical Device Regulation (EU MDR).

ASUS MH series clinical displays include the 32-inch / 8-megapixel MH3281A, the 27-inch / 4-megapixel MH2741A, and the 23.8-inch MH2441A. All are designed for radiology as well as Picture Archiving and Communication System (PACS) use. Each monitor meets the DICOM Part 14 Grayscale Standard Display Function (GSDF) AAPM TG270 standard, and each includes a scheduled calibration feature, dynamic brightness compensation, and dynamic DICOM compensation to ensure consistent and highly accurate medical images. In addition, each monitor features an anti-glare, low-reflection (AGLR) coating on the panel, and each has been certified by TÜV Rheinland to ensure flicker-free performance and low blue light emissions. These clinical displays also meet ISO 13485 requirements.

Specifications[i]

ASUS MH series clinical displays

		MH3281A	MH2741A	MH2441A
Displays	Panel Size	31.5" (80.09cm) 16:9	27" (68.46cm) 16:9	23.8" (60.45cm) 16:9
	Resolution	8MP (3840 x 2160 pixels)	3.6MP (2560 x 1440 pixels)	3.6MP (2560 x 1440 pixels)
	Display Viewing Area (H x V)	698.112 x 392.688mm	596.74 x 335.66mm	526.85 x 296.35mm
	Display Surface	AGLR (Anti-glare, Low-reflection)	AGLR (Anti-glare, Low-reflection)	AGLR (Anti-glare, Low-reflection)
	Panel Type	RGB OLED	IPS	IPS
	Viewing Angle (CR≧10, H/V)	178°/ 178°	178°/ 178°	178°/ 178°
	Pixel Pitch	0.182mm	0.2331mm	0.2058mm
	Brightness (Typ.)	250cd/m2	350cd/m2	300cd/m2
	Contrast Ratio (Typ.)	1,000,000:1	900:1	900:1
	Display Colors	1073.7M (10 bit)	16.7M (8 bit)	16.7M (8 bit)
	Response Time	0.1ms (GTG)	5ms (GTG)	5ms (GTG)
Video Inputs	DisplayPort 1.4	x 1	x 2 (in, out)	x 2 (in, out)
	HDMI® (v2.0)	x 3	x 1	x 1
	USB-C®	x 1 (DP Alt Mode, PD 15W)	x 1 (DP Alt Mode, PD 15W)	x 1 (DP Alt Mode, PD 15W)
	USB Hub	USB 3.2 Gen2 Type-A x 4	USB 3.2 Gen1 Type-C® x 1 + Type-A x 3	USB 3.2 Gen1 Type-C® x 1 + Type-A x 3
	Earphone Jack	Yes	Yes	Yes
Features	Preset Mode	Native / sRGB / DICOM (0, 50, 100,lux) / DICOM_Auto / User Mode 1 / User Mode 2	Native / sRGB / DICOM (0, 50, 100,lux) / DICOM_Auto / User Mode 1 / User Mode 2	Native / sRGB / DICOM (0, 50, 100,lux) / DICOM_Auto / User Mode 1 / User Mode 2
	Color Temp. Selection	6 Modes (5000K / 5500K / 6500K / 7500K / 9300K / 12000K)	6 Modes (5000K / 5500K / 6500K / 7500K / 9300K / 12000K)	6 Modes (5000K / 5500K / 6500K / 7500K / 9300K / 12000K)
	Monochrome	Off / Positive / Native	Off / Positive / Native	Off / Positive / Native
	Gamma Curve	2.0 / 2.2 / 2.4	2.0 / 2.2 / 2.4	2.0 / 2.2 / 2.4
	Aspect Control	Full / Dot to Dot / 1:1	Full / Dot to Dot / 1:1	Full / Dot to Dot / 1:1
	Screen Pixel	8MP / 6MP / 5MP / 3MP	4MP / 3MP	4MP / 3MP
	Picture-in-Picture	Yes	Yes	Yes
	Picture-by-Picture	Yes (2~4 input sources with 2 color engine)	Yes (2 input sources with 2 color engine)	Yes (2 input sources with 2 color engine)
	Uniformity Compensation	NA	Yes	Yes
	OSD Auto Rotation	Yes	Yes	Yes
	HDCP Support	Yes, 2.2	Yes, 2.2	Yes, 2.2
	RGB Tuning	Yes	Yes	Yes
	Blue Light Filter	Yes	Yes	Yes
	Rest Reminder	Yes	Yes	Yes
	Color Augmentation	Yes	Yes	Yes
Sensor	Embedded Colorimeter Sensor	Yes	-	-
	Ambient Light Sensor	Yes	Yes	Yes
	Proximity Sensor	Yes	-	-
Power Requirements	Power On (Typical)	< 23.2W	< 13W	< 14.5W
	Power Saving Mode	< 0.5W	< 0.5W	< 0.5W
	Power Off Mode	< 0.3W (Hard Switch)	< 0.3W (Hard Switch)	< 0.3W (Hard Switch)
	Power Frequency	100~240V, 50/60Hz	100~240V, 50/60Hz	100~240V, 50/60Hz
Mechanical Design	Color	Black / White	Black / White	Black / White
	Antibacterial Treatment	-	Yes	Yes
	Tilt	+23° ~ -5°	+23° ~ -5°	+23° ~ -5°
	Swivel	+30° ~ -30°	+30° ~ -30°	+30° ~ -30°
	Pivot	+90° ~ -90°	+90° ~ -90°	+90° ~ -90°
	Height Adjustment	0~130 mm	0~130 mm	0~130 mm
	VESA Wall Mounting	100 x 100 mm	100 x 100 mm	100 x 100 mm
	Kensington Lock	Yes	Yes	Yes
Dimensions (Est.) (W x H x D)	Phys. Dimension	73.54 x (49.69~62.69) x 24.50cm	61.33 x (40.07~53.67) x 19.72cm	53.96 x (38.51~51.51) x 19.72cm
	Phys. Dimension without Stand	73.54 x 46.69 x 5.44cm	61.33 x 36.34 x 4.49cm	53.96 x 32.22 x 4.46cm
	Box Dimension	87.8 x 61.6 x 29.8cm	69.5 x 42.1 x 13.30cm	62.00 x 39.00 x 12.7cm
Weight (Est.)	Net Weight	14.8kg	6.7kg	5.4kg
	Net Weight without Stand	7.4kg	5kg	3.7kg
	Gross Weight	18.2kg	9.3kg	8.2kg
Reliability	Operating Temperature	0°C ~ 40°C	0°C ~ 40°C	0°C ~ 40°C
	Storage Temperature	-20°C ~ 60°C	-20°C ~ 60°C	-20°C ~ 60°C
	Operating Humidity (RH)	5% ~ 90%	5% ~ 90%	5% ~ 90%
	Storage Humidity (RH)	5% ~ 90%	5% ~ 90%	5% ~ 90%
Regulation		IEC 62368-1, IEC 60601-1, IEC 60601-1-2, ISO13485, RoHS, FDA/TFDA Class I, EU MDR	IEC 62368-1, IEC 60601-1, IEC 60601-1-2, ISO13485, RoHS, FDA/TFDA Class I, EU MDR	IEC 62368-1, IEC 60601-1, IEC 60601-1-2, ISO13485, RoHS, FDA/TFDA Class I, EU MDR
Certification		AAPM TG270, DIN6868, TG18, WHQL Windows 10/11, TÜV Flicker Free, TÜV Low Blue Light	AAPM TG270, DIN6868, IEC62563-1, WHQL Windows 10/11, TÜV Flicker Free, TÜV Low Blue Light	AAPM TG270, DIN6868, IEC62563-1, WHQL Windows 10/11, TÜV Flicker Free, TÜV Low Blue Light
Accessories (Vary by regions)		158.4W Power Adaptor, Power Cord, HDMI Cable, DisplayPort Cable, USB-C Cable, Quick Start Guide, Warranty Card	90W Power Adaptor, Power Cord, HDMI Cable, DisplayPort Cable, USB-C Cable, Quick Start Guide, Warranty Card	90W Power Adaptor, Power Cord, HDMI Cable, DisplayPort Cable, USB-C Cable, Quick Start Guide, Warranty Card
